How to Identify Which Processes Are Using Swap Space in Linux

How to Identify Which Processes Are Using Swap Space in Linux

Understanding and monitoring swap space usage in Linux is crucial for system administrators and power users. Swap space serves as an extension of physical RAM, providing additional memory when the system runs out of physical memory. However, excessive swap usage can severely impact system performance, making it essential to identify and manage processes that heavily utilize swap space.

In this comprehensive guide, we’ll explore how to effectively monitor swap usage and identify problematic processes using both built-in tools and a custom script. This knowledge is crucial for maintaining optimal system performance and troubleshooting Linux systems.

Understanding Linux Swap Space

Swap space serves as an extension of physical RAM, crucial for system stability and performance. When physical memory becomes scarce, the Linux kernel moves less frequently accessed memory pages to swap space, preventing system crashes due to memory exhaustion.

Types of Swap Space

  1. Swap Partition

    • Dedicated partition on storage device
    • Fixed size, better performance
    • Requires partition management
  2. Swap File

    • Regular file in filesystem
    • Flexible size, easily adjustable
    • Slightly lower performance
System RAMRecommended Swap SizeUse Case
2GB or less2x RAMDesktop/Small Server
2GB to 8GBEqual to RAMGeneral Server
8GB to 64GB0.5x RAMHigh-Memory Server
64GB+Minimum 4GBLarge Production Server

Proper system resource management is crucial for maintaining optimal performance, particularly when dealing with swap space.

Methods to Check Swap Usage

Basic Commands

Before diving into process-specific swap usage, let’s look at system-wide swap information using basic commands:

# Check overall memory and swap usage
free -h

# Output

root@cloud:~# free -h
               total        used        free      shared  buff/cache   available
Mem:           7.6Gi       1.8Gi       679Mi        35Mi       5.5Gi       5.8Gi
Swap:          8.0Gi       294Mi       7.7Gi


# View swap statistics
swapon --show

# Output
root@cloud:~# swapon --show
NAME      TYPE SIZE   USED PRIO
/swapfile file   8G 294.3M   -2

# Monitor real-time system statistics
top

Using the /proc Filesystem

The /proc filesystem provides detailed information about running processes and system resources. You can manually check swap usage for a specific process using:

grep VmSwap /proc/<PID>/status

# Output
root@cloud:~# grep VmSwap /proc/1438/status
VmSwap:      512 kB

For all processes

for i in /proc/[0-9]*; do
  awk '/VmSwap|Name|Pid/{printf $2 " " $3}END{ print ""}' $i/status 2>/dev/null
done

Understanding the Swap Monitoring Script

Our custom script provides a more detailed view of per-process swap usage. Let’s break down how it works:

# Print header
printf '%12s %15s  %s\n' Pid Swap\ Usage Command

# Sort by swap usage (2nd column)
sort -nk2 < <(
   sed -ne '
       /^Name:/h;
       /^Pid:/H;
       /^VmSwap:/!b
       H
       x
       s/^.*:\s*\(.*\)\n.*:\s*\(.*\)\n.*:\s*\(.*\) kB/           \2           \3  \1/;
       s/^ *\([0-9 ]\{12\}\)\b *\([0-9 ]\{12\}\)\b /\1 \2 kB /p;
       s/^ *[0-9]\+ \+\([0-9]\+\) .*/+\1/;
       w /dev/fd/9' /proc/[1-9]*/status 9> >(
           printf 'Total:%19d Kb\n' $(( $( cat ) ))
       )
)

The script performs these key functions:

  • Reads process information from /proc
  • Extracts PID, swap usage, and process name
  • Sorts results by swap usage
  • Provides a total swap usage summary

Implementing the Solution

To use the script effectively, follow these steps:

  1. Create a new file (e.g., swap-usage.sh)
  2. Copy the script contents into the file
  3. Make the script executable:
    chmod +x swap-usage.sh

  4. Run the script:
    ./swap-usage.sh


The output will look similar to:

Pid      Swap Usage  Command
1461            0 kB  dumb-init
1822            0 kB  containerd-shim
1943            0 kB  containerd-shim
2113            0 kB  containerd-shim
2309155            0 kB  tail
2309985            0 kB  containerd-shim
2310006            0 kB  npm run start
2310051            0 kB  sh
2310052            0 kB  node
2674878            0 kB  multipathd
3167786            0 kB  pickup
3169626            0 kB  systemd
3169629            0 kB  (sd-pam)
3169717            0 kB  bash
3169827            0 kB  sort
3169828            0 kB  sed
449122            0 kB  containerd-shim
449189            0 kB  sh
449190            0 kB  node
449449            0 kB  containerd-shim
458198            0 kB  tail
458206            0 kB  tail
458286            0 kB  tail
459036            0 kB  tail
459133            0 kB  tail
459142            0 kB  tail
463698            0 kB  tail
463964            0 kB  tail
504465            0 kB  tail
504706            0 kB  tail
562701            0 kB  tail
564403            0 kB  tail
712927            0 kB  tail
779            0 kB  atd
988208            0 kB  tail
1694          128 kB  master
1696          128 kB  qmgr
756178          128 kB  polkitd
762          128 kB  cron
769          128 kB  qemu-ga
902          128 kB  agetty
905          128 kB  agetty
91220          128 kB  agent
449468          256 kB  traefik
763          256 kB  dbus-daemon
813          256 kB  rsyslogd
  1          384 kB  systemd
449412          384 kB  docker-proxy
1362          512 kB  containerd-shim
1438          512 kB  containerd-shim
264777          512 kB  systemd-udevd
449082          512 kB  docker-proxy
91200          512 kB  containerd-shim
1295          640 kB  containerd-shim
1829          640 kB  docker-proxy
264759          640 kB  systemd-journal
264766          640 kB  sshd
264771          640 kB  systemd-timesyn
449099          640 kB  docker-proxy
449392          640 kB  docker-proxy
449403          640 kB  docker-proxy
449420          640 kB  docker-proxy
778          640 kB  systemd-logind
3169622          728 kB  sshd
1808          768 kB  docker-proxy
1915          768 kB  docker-proxy
1926          768 kB  docker-proxy
264780          768 kB  systemd-network
2043         1024 kB  redis-server
524744         1024 kB  postgres
653062         1024 kB  postgres
653861         1024 kB  postgres
654028         1024 kB  postgres
654029         1024 kB  postgres
654030         1024 kB  postgres
654031         1024 kB  postgres
654032         1024 kB  postgres
654033         1024 kB  postgres
2829330         1124 kB  postgres
2958425         1124 kB  postgres
3021373         1124 kB  postgres
3035581         1124 kB  postgres
3122741         1124 kB  postgres
3140881         1124 kB  postgres
1964         1152 kB  postgres
2300         1152 kB  postgres
2301         1152 kB  postgres
2310         1152 kB  postgres
2311         1152 kB  postgres
2547         1152 kB  query-engine-de
2309         1280 kB  postgres
264770         1408 kB  systemd-resolve
2155         1792 kB  postgres
2333         1792 kB  postgres
2334         1792 kB  postgres
2340         1792 kB  postgres
2341         1920 kB  postgres
2342         2048 kB  postgres
780         3328 kB  containerd
875         6528 kB  dockerd
812         9344 kB  unattended-upgr
1387        12416 kB  gunicorn
449142        17536 kB  node
1588        42496 kB  next-server (v1
1315        61568 kB  litellm
1746       112000 kB  gunicorn
Total:             318256 Kb

Managing High Swap Usage

When you identify processes with high swap usage, consider these management strategies:

  1. Immediate Actions:

    • Kill unnecessary processes
    • Restart memory-hungry applications
    • Clear system cache
  2. Long-term Solutions:

To modify system swappiness:

# Check current swappiness
cat /proc/sys/vm/swappiness

# Temporarily modify swappiness
sudo sysctl vm.swappiness=60

# Permanently modify swappiness
echo 'vm.swappiness=60' | sudo tee -a /etc/sysctl.conf

Additional Tools and Resources

Besides our custom script, consider these additional tools for monitoring system resources:

  1. htop - Interactive process viewer
  2. vmstat - Virtual memory statistics
  3. Docker stats - For containerized environments
  4. sysstat package tools

Remember to regularly monitor your system’s performance using these tools and maintain proper system security practices.

Conclusion

Monitoring swap usage is crucial for maintaining optimal system performance. The provided script and methods in this guide will help you identify and manage processes that heavily use swap space. Regular monitoring and proactive management of swap usage will ensure your Linux system runs efficiently and reliably.

For more Linux administration tips and tools, check out our guides on Linux commands and system monitoring.
